230V power supply 20W with USB C to USB-C adapter cable | sCharge s48 C
The world’s first flush-mounted power supply unit that delivers 20W in a wall box that is only 40mm deep. But not only the power supply is flush-mounted, also the USB plug does not protrude beyond the wall. This allows for very flat installations in front of the wall.
Nominal input: 100 – 250 V ~, ±10 % , 50 – 60 Hz,
Nominal output: 5 V 3A and 9V 2,22A
Specificaties
SKU manufacturer
- smart:)things sCharge s48 C
Specifications
- Connection: USB-C
- Nominal input: 100 – 250 V ~, ±10 % , 50 – 60 Hz,
- Nominal output: 5 V 3A and 9V 2,22A
- Input voltage: 100-240V~/50-60Hz
- Output: 5V (3A) en 9V (2,2A), 20W
- Comes with angled USB-C to USB-C cable
Scope of delivery
- In-wall Charger 20W with USB-C cable, 30 cm long
- Instructions in EU languages, Turkish, Russian, Chinese.
Material
- Metal support frame, plastic housing
- RoHS compatible
- WEEE registration: DE 64398562
Dimensions
- Box 80 x 80 x 50 mm (HxWxD)
- Product 71 x 71 x 33 mm with metal frame
Weight
- 120 g (incl. adapter cable and packaging)
Approvals:
- KEMA (EUR)
- Low Voltage Directive LVD EN 62368-1:2014 + A11:2017
EMC Directive EN 50032:2015 - Ecodesign Directive 2009/125/EC, 2019/1782/EC
- RoHS Directive 2011/65/EU, 2015/863
- Reach Regulation EC No 1907/2006, 1272/2008
Product informatie
USB wall socket for installation in a standard flush-mounted box. The ideal adapter to continuously charge your iPad or tablet with USB-C when mounted flat on the wall.
Tablet on the wall
You can mount the charger in a normal wall socket, over which you place an iPad or tablet wall mount. Unlike normal adapters that are not suitable for mounting in the wall, this product is specially designed for mounting in the wall. Almost every other USB wall socket is on the wall instead of in the wall and requires a normal USB cable that sticks out quite a bit. This USB wall socket is in the wall and is completely flat except for the cable, making it easy to place a wall holder over the adapter.
Home Automation
Very suitable for home automation, operation of Philips Hue and Spotify, for example. With this built-in charging station, cables are hidden and the iPad or tablet receives continuous power. Your tablet is charged, without visible cabling, flat on the wall. This built-in charging station is very suitable for use in combination with a large part of our iPad wall mounts and tablet wall mounts. If in doubt, please contact us.
Suitable for mounting in a standard 40 mm single socket outlet. Not suitable for surface mounting.
